Descripción
Rigol DNA5000 Serie de Analizadores Vectoriales de 2 puertos hasta 26,5GHz
The Rigol DNA5000 Vector Network Analyzer empowers you to precisely capture S-parameters, assessing your device’s full transmission and reflection profile. Effortlessly tackle impedance matching with intuitive Smith charts and polar plots, and rapidly diagnose cable and antenna issues using the powerful Distance-to-Fault (DTF) function.
Delivering a frequency range from 5 kHz to 26.5 GHz with 2 standard test ports, this Rigol DNA5000 analyzer precisely covers testing requirements ranging from basic passive components to material dielectric constant analysis and high-speed interconnects.
Product Fearures:
- Frequency range: 5kHz-26.5GHz (DNA5262), 5 kHz-20GHz (DNA5202), 5 kHz-14GHz (DNA5142), 5kHz-8.5GHz (DNA5082), 5kHz ~ 4.5 GHz (DNA5042).
- Number of Ports: 2.
- Frequency resolution 1 Hz.
- Max. output power 10 dBm.
- High dynamic range 127 dB (typ.).
- Trace noise: 0.005 dB.
- IF BW: 1 Hz to 10 MHz.
- Compatible with the mechanical calibration kit and the Ecal electronic calibration kit, supporting various calibration types (SOLT, Response Short, Response Open, OSL, Enhanced Response 1 to 2, Response Through).
- Integrates S-parameters, impedance, VSWR, TDA, fixture embedding/de-embedding, antenna test, and etc.
- Portable and light-weighted design, with the compact size of (358.1 mm x 214.8 mm x 121.4mm) and light weight of 5.3 kg.
- 10.1” 1280×800 HD touch screen.
- Supports LAN, USB Device, USB Host, and HDMI interfaces.
- Supports standard SCPI instruction sets.
- Supports Web Control for remote operation.
- Supports both physical key operation and touch screen operation; allowing you to use externally connected keyboard and mouse to input values.
