Itech IT-N6700 Programable DC Power Supply series until 1500V
The ITECH IT-N6700 Series Programmable DC Power Supply is designed to meet high power density and performance requirements, widely used in automated test equipment (ATE), R&D laboratories, semiconductor testing, and power electronics. The ITECH IT-N6700 series offers 1000W and 1500W power options, with a voltage range from 32V to 1500V, catering to various testing needs. Its compact 1/2 2U rack design delivers powerful output in limited space. Equipped with a high-definition LCD screen, it provides not only traditional numeric measurements but also waveform trend display, allowing real-time monitoring of parameter changes during the testing process.
Características principales:
- 4.3-inch LCD screen.
- Three output modes: CC/CV/CP.
- Wide range : 32V-1500V, 1000W & 1500W.
- LIST mode, adjustable rise/fall slope.
- CC/CV priority mode for compatibility with various DUTs.
- Trend analysis function for monitoring long-duration U/I/P curves.
- Remote sensing compensation.
- Rich protections: OCP/OVP/UVP/OPP/OTP/Foldback.
- Standard USB/LAN/RS232/Digital I/O communication interfaces.
